Allen Bradley 2711-K6C2 Standard Operator Terminals

• Input Voltage Range: 85…264 VAC
• Input Frequency: 47…63 Hz
• Application Runtime Memory: 190 KB
• Non-Volatile Memory: 240 KB
• Display Size: 5 inch
• Display Type: Color Active Matrix TFT LCD
• Display Color: Color
• Display Area: 115 x 86 mm (4.54 x 3.4 in.)
• Resolution: 320 x 234 Pixels

The 2711-K6C2 display panel is a PanelView 600 series display panel manufactured by Allen-Bradley. This operator terminal has a DH485 communication port can be used along with a 1747-UIC communication cable. The display terminal lets users monitor, control, and view status information graphically. The 2711-K6C2 display panel has a color display which is 5 inches wide and has a resolution of 320 x 240. The display panel is powered with AC power in the range of 85 to 264 Volts AC. The display terminal has an internal memory size of 240 KB non-volatile memory and 190KB Random Access Memory (RAM). The display panel weighs 6 pounds and it has dimensions of 14 x 11 x 8 inches.

The 2711-K6C2 has a field replaceable backlight rated at 50,000 hours of half-life if the display panel is maintained at 25 degrees Celsius. The integrated keypad in the display is a stainless-steel domed membrane with navigation, function, and power keys that can take 2 million presses. The 2711-K6C2 display panel has 10 function keys that are used for different commonly-used functions. The battery used this display panel variant is field-replaceable. The display comes with 190 KB of application runtime memory and 240 KB of non-volatile memory for application objects and text and bitmaps. The display panel does not support an ATA memory card.

The 2711-K6C2 features a multiple number of fully programmable keypad. This keypad assembly is composed of Ten (10) function keys, a numeric keypad set and navigation buttons for selection of objects.

The display screen is a 5-inch colored screen which allow users to view the process in a more detailed manner. The colored screen allows implementation of color-coded animation which may be used to depict plant and device status, as well as provide information such as alarm severity and event criticality. The screen has a display size of 115 x 86 mm (4.54 x 3.4 in.) and resolution of 320 x 234. It is built with an internal backlight that is designed to operate up to 50,000 hrs.
