Allen Bradley 5094-OW8IXT Isolated relay output module

• Output Delay Time (OFF to ON): 10 ms max
• Output Delay Time (ON to OFF): 10 ms max
• Operating Voltage Range: 5…125V DC / 5…240V AC
• Contact Type: Dry Relay Contact
• Maximum Power Dissipation: 3.5 W
• Maximum Thermal Dissipation: 11.94 BTU/hr
• Operating Temperature Range: -40…70°C
• Weight: 0.91 kg (2.00 lbs)

The Allen-Bradley 5094-OW8IXT module is a safety output module from the Allen-Bradley FLEX 5000 module series that has 4 isolated relay outputs. There are 2 outputs that are 2 Amps rated resistive channels that operate at 5 to 30 Volts DC or at 5 to 240 Volts AC at 50 to 60 Hertz frequency. There is also a single 2 Amps rated general channel that operates at 5 to 240 Volts AC at 50 to 60 Hertz frequency, and a single 2 Amps rated ATEX/IECEx that operates at 5 to 240 Volts AC at 50 to 60 Hertz frequency. The 5094-OW8IXT module’s outputs are not fused. The off-state leakage on the 5094-OW8IXT safety output module is 0 milliamps with dry contacts and no onboard snubbers and its maximum output current rating is 2 Amps per output channel.

The Allen-Bradley 5094-OW8IXT FLEX 5000 safety output module has 10 milliseconds of maximum off to on output delay time and an equal amount of maximum on to off output delay time. This output module can operate with AC or DC voltage in voltage ranges of 5 to 125 Volts DC or 5 to 240 Volts AC. Its maximum power dissipation rating 3.5 Watts and its maximum thermal dissipation 11.94 BTU/hour. The 5094-OW8IXT module uses Wire Category 1 for the signal ports and Wire Category 2 for the power ports. This safety output module can operate safely at a temperature between -40 and 158 degrees Fahrenheit. This wide temperature range allows the module to be used a variety of different industrial environments and applications.
