Allen Bradley MPL-A310P-SJ72AA MPL Servo Motors

• Voltage Class: 200V AC
• Rated Voltage: 200 Volts
• Frame Size: 100 mm
• Flange Standard: IEC 72-1 Flange
• Magnetic Stack Length: 1 inch
• Rated Speed: 5000 RPM
• Enclosure Rating: IP50
• Connector Rotation: 180° Rotatable
• Weight: 10.00 lbs (4.54 kg)

The catalog number MPL-A310P-SJ72AA is an order reference for an Allen-Bradley/Rockwell Automation servo motor from the MPL series. This MPL series servo motor is a low-inertia servo motor with all of the standard factory designated options. The typical mounting flange for the MPL series servo motors like the MPL-A310P-SJ72AA servo motor is an IEC metric mounting flange. The MPL-A310P-SJ72AA servo motor does not include a brake like some of the other MPL series servo motors do. Additionally, it should be noted that the MPL series servo motors are equipped with either circular bayonet connectors or circular DIN connectors and the MPL-A310P-SJ72AA servo motor includes the circular DIN type of connectors that are 180 degrees rotatable for connection flexibility.

The Allen-Bradley/Rockwell Automation MPL-A310P-SJ72AA MPL series servo motor offers a maximum rotor speed of 5000 revolutions per minute (RPM) and it comes with an encoder feedback option. The feedback encoder option that is built into this servo motor is a single-turn high-resolution type of encoder. The MPL-A310P-SJ72AA servo motor operates at 200 Volts of rated voltage and it can operate under tough operating conditions. This servo motor is rated with an IP 50 IP rating or Ingress Protection rating and it can be stored at extremely low and high temperatures. However, the operating temperature of the unit should always be above 0 degrees Celsius (32 degrees Fahrenheit) but not higher than 40 degrees Celsius (104 degrees Fahrenheit). Some motors from the series with optional shaft seals have ingress protection ratings of IP 66. The MPL-A310P-SJ72AA servo motor has a shaft key but no shaft seal.
