Schneider LC1-D50BD contactor

• Product Series                                                        TeSys Deca
• Product Type                                                          3-Pole Contactor (3NO)
• Application                                                           Motor Control
• Rated Operational Current                                             50A (AC-3/3e @ 690V)
• Rated Motor Power                                                     22kW @ 400V
• Coil Voltage                                                          24V DC (with Transient Suppressor)
• Auxiliary Contacts                                                    1NO + 1NC (Mirror Certified NC)
• Power Terminals                                                       Screw Terminals
• Control Terminals                                                     Screw Clamp Terminals

TeSys Deca contactor, 3 poles (3NO), for motor control applications up to 50A/690V AC-3/3e (22kW@400V). They can be used to create motor starters for almost any type of application. It provides a 24V DC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), power connection by screw terminals, control connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (75mm width), DIN-rail mounting or screw fixing. Contactor is rated for 15HP at 200 to 208VAC, 15HP at 240VAC, 40HP at 480VAC and 40HP at 600VAC three phase. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine). When used with a 480VAC up to 110A circuit breaker, this contactor can have a SCCR up to 100kA. When used with up to a 600VAC 110A Class J or CC fuse, this contactor can have a SCCR up to 100kA.
