Schneider LE1D09P7 Enclosed DOL starter

• Operating Temperature: -5…40°C
• Height: 166 mm
• Width: 88 mm
• Depth: 128.5 mm
• Product Weight: 0.92 kg
• Number of Poles: 3P
• Rated Thermal Current (Ithe): 9 A
• Rated Voltage: 690 V AC
• Motor Power Rating: 4 kW at 400 V AC-3
• Coil Voltage: 230 V AC
• Coil Frequency: 50/60 Hz

TeSys enclosed starter with contactor, 3 poles, Ithe 9A 690V, for non-reversing motor applications up to 4kW@400V AC-3. Polycarbonate enclosure providing IP65 / IK07 protection, equipped with a green pushbutton Start (I) and a red pushbutton Stop/Reset (O). It includes a contactor LC1D with a control circuit 230V 50/60Hz. To operate, it must be fitted with a thermal overload relay LRD02-LRD14 depending on the motor power (to be ordered separately). Surface mounting enclosure with screw fixing, 2 knock-outs for cable glands on top and bottom. It conforms to IEC 60947-4-1.
