Allen Bradley 5094-AENTRXT Ethernet adapter

• Terminal Torque: 0.4 N·m
• Functional Earth Terminal Torque: 0.5 N·m
• Wire Temperature Rating: 105°C
• Wiring Category: Category 1 on power ports
• Operating Temperature: -40…70°C
• Product Weight: 0.91 kg
• Module Current Rating: 1250 mA
• MP Voltage and Current Rating: 18…32 V DC, 1880 mA
• Backplane Current: 1130 mA
• SA Power: 20 A @ 250 V AC

The 5094-AENTRXT adapter is an Allen-Bradley manufactured Ethernet/IP adapter. The adapter is used for internal communications. It can also be used to upload and download files and information over the network. The adapter is fully compatible with a variety of Allen-Bradley products. These adapters are equipped with RJ-45 ports. The adapter has a current rating of 1250 milliamps. It supports a voltage range between 18 and 32 Volts DC. The adapter is powered with a backplane current of 1130 milliamps. The recommended external overcurrent protection lies in between 10 and 12 Amps at 22.5 Volts DC. The 5094-AENTRXT adapter dissipates 5.1 Watts of power in the form of heat with a voltage rating of 18 Volts DC. The thermal dissipation of the adapter is 17.4 BTU per hour with a voltage rating of 24 Volts DC. The adapter can be mounted using a DIN Rail made up of zinc plate or chromate passivated steel. A separate removable terminal block is available with the Ethernet/IP adapter.

The 5094-AENTRXT adapter has a terminal block torque of the 0.4 N-m screw type. The functional earth terminal comes with a terminal block torque of 0.5 N-m. The adapter can be used within a temperature range of -40 and 70 degrees Celsius with a surrounding air temperature of 70 degrees Celsius. The environment should be relatively humid with a maximum rating of 95%, non-condensing. The 5094-AENTRXT adapter has a continuous isolation voltage rating of 300 Volts. It has basic insulation. The adapter uses a 14 AWG solid or stranded copper wire that is rated at 105 degrees Celsius.
