Allen Bradley 1746-NI16V Analog Input Module

• Number of Inputs: 16 Channels
• Input Type: Analog Voltage Input
• Backplane Current (5V DC): 125 mA
• Backplane Current (24V DC): 75 mA
• Weight: 0.40 kg (0.88 lbs)

The Allen Bradley 1746-NI16V is an Analog Input Module from the SLC 500 series. The 1746-NI16V communicates with an SLC 500 processor through a parallel rear-facing interface, and receives power from the SLC 500 power supply via a backplane. Its operating temperature lies between -25 to 60 degrees Celsius (-13 to 140 degrees Fahrenheit), while its nonoperating temperature lies between -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit). The relative humidity of this module ranges from 5% to 95% without condensation. This module belongs to a Voltage Category of-10 to +10 Volts DC. The backplane current at 5 Volts is 125 mA; at 24 Volts, this module’s backplane current is 75 mA. The backplane power consumption of this module is 2.425 Watts max (0.625 Watts at 5 Volts DC and 1.8 Watts at 24 Volts DC). Removing or inserting a module while a power source is connected can cause an electric arc to occur; remember to disconnect the power before removing or inserting this module. The Allen Bradley 1746-NI16V has 16 input channels and a 16-bit resolution. The common mode voltage range of this module is +/-10.25 Volts relative to the analog common terminal. Its input impedance is 20 Ω and its AIFM Connector is 25-pin D-shell. This module has Standard Cable Lengths of 0.5, 1, 2.5, and 5.0 meters. It has a Gain drift of 15 ppm/degree Celsius, and the Input offset drift of this module is 90 mV/degree Celsius. The Input resolution of this module is 312 mV.
