Allen Bradley 1783-US5TG unmanaged switch

• Weight: 1.00 lbs (0.45 kg)
• Product Family: Stratix Ethernet Switch
• Number of Copper Ports: 5
• Transmission Speed: 10 / 100 / 1000 Mbps
• Number of Fiber Ports: None
• Supply Voltage Range: 12–48V DC; 18–30V AC (50/60 Hz)
• Nominal Supply Voltage: 24 VAC / VDC
• Power Consumption: 4.5 W
• Inrush Current: 0.33 A
• Total Ports: 5
• RJ45 Ports: 5 Gigabit Ethernet
• SFP Ports: 0
• Max Inrush Current: 0.33 A
• Power Input: 24V (12 to 48V DC, 18 to 30V AC, 50/60 Hz), SELV
• Max Power Consumption: 4.5 W

The Allen-Bradley 1783-US5TG is an unmanaged switch designed specifically for network connectivity and device interconnection. It addresses the requirements for Ethernet communication expansion and high-performance data transmission within automated production lines and device networks, finding application in scenarios such as PLC control systems, automated production lines, and device networking.

The 1783-US5TG is an Allen-Bradley industrial Ethernet switch that belongs to the Stratix 2000 Unmanaged Ethernet switch product family. This Ethernet switch is a DIN rail mounted device, primarily used for industrial Ethernet network connectivity, allowing automation devices such as Programmable Logic / Automation Controllers (PLC / PAC), Human Machine Interfaces (HMI), Supervisory Control and Data Acquisition (SCADA) systems and field devices some of which includes Adjustable Frequency AC drives, Soft starters, gateways, and other devices. This ethernet switch is compatible for use with Allen-Bradley and 3rd party products that are Ethernet enabled. The 1783-US5TG is provided with Five (5) Ethernet copper ports. These ports are designed for the insertion of RJ45 connectors and support 10/100/1000 Mbps transmission speed. It has an inrush current rating of 0.33 Ampere, power consumption of 4.5 Watts nominal input current of 250 mA at DC input and 500 mA at AC input while the maximum input current is 510 mA at DC input and 750 mA at AC input. This ethernet switch operates at an input supply voltage of 24 VDC / 24 VAC nominal with voltage ranges of 12 - 48 VDC and 18-30 VAC along with an input frequency of 50-60 Hz at AC input. The 1783-US5TG comes with an open type enclosure and requires 2.5 mm2 (14 AWG) copper wire for ground connection and 4…0.25 mm2 (12…24 AWG) twisted-pair copper wire for DC power connection. Recommended tightening Torque are 0.91 N-m (8.05 in-lb) for ground terminal and 0.50…0.56 N-m (4.5…5.0 in-lb) for power terminals.

This Stratix 2000 Unmanaged Ethernet Switch by Allen Bradley, the 1783-US5TG is ideal for small, isolated network applications. It can be used with both AC and DC power, providing flexibility in the requirements of power. It also includes an automatic detection feature to detect cable crossovers. It has a total of five (5) ports, all of which are GE (Gigabit Ethernet) RJ45 copper ports that have a 10/100/1000 Mbps data rate. It has a maximum inrush current of 0.33 A, the input power is 24 Volts nominal (12 to 48 Volts DC, 18 to 30 Volts AC, 50 to 60 Hertz) with SELV safe value, and it consumes 4.5 Watts of power at maximum. For ground connection, 2.5 (14 AWG) copper wire is suitable and for DC power connection, 4 to 0.25 (12 to 24 AWG) twisted-pair copper wire is suitable. The 1783-US5TG new series B switch offers additional features to provide reliable network connectivity. Its design is further decreased in size to maximize cabinet space, and its environmental ratings are enhanced for industrial applications from IP20 to IP30 (Ingress Protection) with a rugged metal enclosure. Its operational temperature range is extended drop as low as -40 degrees Celsius and peak at 75 to meet the needs of a wide variety of applications. It also features broadcast storm protection against unwanted network traffic.

Allen-Bradley is an industrial automation brand with a history spanning over a century. Years of accumulated expertise have rendered its products exceptionally reliable—a key reason why it remains a top choice for customers when selecting industrial automation solutions.

Furthermore, we provide a 12-month warranty on all our products, ensuring a secure and worry-free experience throughout your subsequent usage. You may purchase with complete confidence.

Revision Part

1783-US5TG/A
