Omron E6B2-CWZ6C 1000P/R 2M Rotary Encoder

• Categorise Incremental Shaft model
• Diameter 40 mm dia.
• Power supply voltage 5 to 24 VDC (-5% to +15%) Ripple (p-p) 5% max.
• Current consumption 80 mA max.
• Resolution 1000 P/R
• Inrush current Approx. 9 A (0.3 ms)
• Output phases A, B and Z
• Starting positional point Equipped
• Max. response frequency 100 kHz
• Phase difference on output 90±45 ° between A and B (1/4 T ± 1/8 T)
• Rise and fall times of output 1 µs max. (Cable length: 2 m max., output voltage: 5 V, load resistance: 1 kΩ)
• Starting torque 0.98 mN.m max.
• Moment of inertia 1 x 10-6 kg.m2 max.
• Shaft loading Radial: 30 N
• Thrust: 20 N
• Max. permissible rotation 6000 r/min
