Schneider 140DDI36400 discrete input module

Schneider Electric's 140DDI36400 is tailored for applications requiring low-voltage DC discrete input management. This module encompasses 96 channels for digital input, accommodating voltages from 19.2 V to 30 V DC, with a high-state voltage capability reaching up to 30 V. For low-state recognition, a threshold of no more than 5 V DC is maintained.

The device operates on a positive logic principle utilizing a sinking input format, which can be ideal for various control tasks. Each channel features an input resistance of 6700 ohms, resulting in a rapid switching response time noted as ≤ 2 milliseconds for transitions from off to on, and ≤ 3 milliseconds for the reverse. Furthermore, it can tolerate 30 V continuously and withstand transient pulses of up to 50 V, ensuring robustness in demanding environments.

Heat generation is minimal at 1.35 watts, increasing by 0.13 watts for each active input channel. With an electrical isolation rating of 500 Vrms, the module provides segment protection between channel groups. The current required from the bus is approximately 270 mA, reflecting its efficiency.

Designed in a standard modular format, the 140DDI36400 integrates seamlessly into control panels or systems. Status is easily readable with 96 green LEDs indicating the input state, a red LED for any faults encountered, and an additional green LED to denote bus communication. The module weighs around 0.3 kg (0.7 lb), adding minimal installation burden.

FAQs

What is the maximum continuous input voltage for the 140-DDI-364-00?

The module can handle a continuous input of up to 30V DC, with a short-term maximum input of 50V for a decaying pulse.

What is the response time for state transitions?

The response time is ≤3 Ms when transitioning from state 1 to state 0, and ≤2 ms from state 0 to state 1, ensuring prompt signal processing.

Does the module feature diagnostic LEDs?

Yes, it has 96 green LEDs for input status, a red LED for fault detection, and a green LED to indicate bus communication status, facilitating diagnostics.

What logic type does the 140-DDI-364-00 use?

This module operates on positive (sink) logic, which is common in 24V DC systems and enhances noise reduction.

How is the power dissipation calculated?

The base power dissipation is 1.35 W, plus an additional 0.13 W for each active input point, allowing for efficient energy use tailored to the active input load.
