Schneider TSXDSY16S5 discrete output module

• Protection Degree: IP20
• Protective Treatment: TC
• Pollution Degree: 2
• Operating Temperature: 0...60°C
• Storage Temperature: -25...70°C
• Certification Mark: CE
• Current Consumption: 220 mA at 5 V DC
• Product Weight: 0.31 kg

The Schneider Electric TSXDSY16S5 discrete output module is built to serve critical tasks within micro PLC applications. It provides 16 discrete outputs that are triac protected, ensuring robust operational performance under varying loads. The module is conducive to a voltage range from 48 to 240 V AC, compliant with the EN/IEC 61131-2 standards for reliability and safety. For effective channel handling, currents can reach up to ≤ 1 A, while the cumulative output per module does not exceed 12 A.

Power consumption is nominal at 220 mA when operating at 5 V DC, ensuring efficient usage of power resources. Each output offers a rapid response time, with both activation and deactivation occurring in less than 10 milliseconds. Reliability is further enhanced with a Ge-Mov output overvoltage protection and an isolation resistance exceeding 10 MOhm at 500 V.

The TSXDSY16S5 module's design includes integrated fast blow fuses that provide both short-circuit and output overload protection at a threshold of 5 A, safeguarding against potential system faults. The electrical connections are made via a screw terminal block, allowing for straightforward and secure installation. The module is marked with CE certification, indicating compliance with relevant European standards. Power dissipation calculations are straightforward, expressed as 0.85 W plus 1 W for each output channel multiplied by the current per module, ensuring users can assess the thermal management requirements accurately.

Advantage Products

FAQs about the Schneider Electric TSXDSY16S5 Discrete Output Module:

What is the Schneider Electric TSXDSY16S5 Discrete Output Module?

The TSXDSY16S5 is an I/O (Input/Output) module designed for industrial automation systems. It provides precise control over 16 output signals, making it ideal for applications requiring reliable and accurate output control.

What are the key features of the TSXDSY16S5 Discrete Output Module?

The TSXDSY16S5 module offers a wide range of features, including triac-protected discrete outputs, a voltage range of 48 to 240 V AC, a current capacity of up to 1 A per channel, fast response times, built-in protections against overvoltage, overload, and short-circuit conditions, high isolation resistance, and low power dissipation.

What is the purpose of a discrete output module in industrial automation?

Discrete output modules, like the TSXDSY16S5, control external devices or actuators in industrial automation systems. They provide on/off control signals to devices such as solenoid valves, motors, lights, and relays, allowing precise control over industrial processes.

What is the voltage range supported by the TSXDSY16S5 Discrete Output Module?

The TSXDSY16S5 supports a voltage range of 48 to 240 V AC conforming to EN/IEC 61131-2, with an extended range of 41 to 264 V. This wide voltage range ensures compatibility with various industrial power systems and applications.
