Allen Bradley 160-BA03NPS1 Variable Speed Drive

• Phase Input: 3
• Model: Preset Speed
• Current Rating: A03
• Input Voltage: 380–460 V AC
• Enclosure Type: Open (IP20)
• Input Phase: 3-Phase
• Model Type: Preset Speed
• Output Voltage: 380–460 V AC
• Series: C
• Output Phase: 3-Phase
• Max. Output Amps: 2.3
• Output Power: 1.0 HP or 0.75 kW
• Operational Input Voltage Range: 340–506 V AC
• Output Current: 2.3 A
• Input Current: 2.8 A
• Output Frequency: 0–240 Hz
• Cooling Method: Fan
• Interface Module: via the optional program keypad module
• Communication Ports: via communication modules
• Control Method: V/Hz
• Product Lifecycle Status: Discontinued / Obsolete
• Enclosure: IP20, NEMA/UL Type Open
• Mounting: DIN Rail / Panel Mount

The 160-BA03BPS1 is an Allen-Bradley manufactured Variable Speed Drive (VSD) that belongs to the Bulletin 160 of Smart Speed Controller (SSC). This variable Speed Drive (VSD) is a compact, scalable device designed for simple and general-purpose speed control requirements. It implements control using Volts / Hertz (V/Hz) control with an adjustable ratio of the two variables to suit the control requirements of the process. This drive is a Preset Speed model, able to provide modulating speed control via pre-defined speeds, triggered via the external open collector inputs wired to the control input terminals. The 160-BA03BPS1 is capable of being configured with up to 8 preset speeds and 2 acceleration a/ deceleration profiles. In addition, this drive is also capable of being parameterized with different stopping modes such as Ramp to Stop, Coast to Stop, DC Injection, and DC Injection Braking with Auto Stop. It also comes with built-in protection features that protect the drive in the event of an Overcurrent, Overcurrent Programmable limit, 200% of Hardware Limit, 300% of Instantaneous Fault Excessive Temperature, Over/Under Voltage, Ground Short, and Output Short Circuit. It is also capable of Control Ride Through and Faultless Ride Through. The 160-BA03BPS1 operates when applied with 380-460 VAC, 3-Phase input voltage along with an input current of 2.8 Amperes and input power of 2200 VA. It delivers an output voltage of 380-460 VAC, 3-Phase, output current, and power of 2.3 Amperes and 1.0 HP or 0.75 kW, respectively. This drive has an Open (IP20) enclosure and supports DIN-rail and Panel Mounting.

The 160-BA03BPS1 is a Bulletin 160 variable speed drive, manufactured by Allen Bradley. This A.C drive has dimensions of 6.00 x 3.15 x 6.51 inches. This device is relatively light, with a 1.02-kilogram weight. This user should regularly examine the DC bus voltage on the 160-BA03NPS1, in order to ensure that the device is running properly. The test probes allow easy examination of the speed drive. The 160-BA03NPS1 has been fitted with reliable DC bus test points that enable the user to check the module’s voltage. Apart from that, the device also has LED-ready indicators and fault indicator LEDs. The ready indicator lights up when the 160-BA03NPS1 is completely charged and is all set to run, while the fault indicator alerts the user whenever a fault arises. The 160-BA03NPS1 has a 3-phase motor rating of 0.75 kW. Its maximum output current is 2.3 A. This device’s input frequency is between 50 and 60 Hertz with a functional input voltage of 340 to 506 Volts AC. This device has an input current of 2.8 A and it dissipates an average power amount of around 37 Watts. With these specifications, the 160-BA03NPS1 makes a very powerful and dynamic speed drive.
